WPC Extrusion Line
Model:YT-450
Yongte is a professional manufacturer based in China for WPC extrusion line for recycling waste PP/PE plastic and various fiber materials, it adopts optimized mechanical structure and exclusive formula, realizing high automation, low energy consumption and stable mass production.. The finished WPC products include outdoor decking, wall cladding, fences and pergolas, which are widely sold to Canada, Romania, Poland and other global markets. We help customers realize waste recycling, cost reduction and green production.
WPC Turnkey Production Line | Recycle Waste Plastic & Wood to Eco Building Materials
✅ CE Certified | ✅ 70% Max Wood Powder Ratio | ✅ 15-20% Energy Saving | ✅ 3-Year Full Warranty
Yongte is a professional Chinese manufacturer of WPC extrusion lines. Our WPC extrusion line WPC production line is a mature turnkey solution designed for recycling waste PP/PE plastics and various fiber materials. Featuring high automation, low energy consumption and stable mass production, our equipment produces outdoor decking, wall cladding, fences and pergolas, which are widely exported to Canada, Romania, Poland and other global markets. We help clients achieve waste recycling, cost reduction and green manufacturing.
Main Advantages:
Technical Specification
Table 1: Raw Material Formula & Configuration
| Category | Details | Parameters & Description |
|---|---|---|
| Main Raw Materials | Plastic | Recycled PP / PE waste plastics (films, bags, bottles, tanks, etc.) |
| Fiber & Fillers | Wood powder, fiberglass, sand, recycled PCB materials, waste textile fibers | |
| Fiber Proportion | 60% - 70% (Max 70% wood powder) | |
| Additives | Functional Additives | PE wax, stearic acid, coupling agent, color pigments |
| Surface Protection | Co-extrusion Layer | Modified functional masterbatch, anti-UV & anti-aging, over 10 years outdoor service life |
Table 2: Full Line Single Equipment Technical Parameters
| Equipment Name | Core Configuration | Production Capacity | Main Function |
|---|---|---|---|
| Plastic Recycling Machine | Integrated crushing, washing, dewatering, squeezing & drying | 300-500 kg/h | Process waste PP/PE plastic into qualified plastic raw materials |
| Wood Powder Making Machine | Log chipping → Chip crushing → Sawdust grinding | 400-500 kg/h | Process raw wood into uniform fine wood powder |
| Heating Mixing Machine | High-speed heating mixer | 500-600 kg/h | Uniformly mix wood powder, plastics and additives |
| WPC Granulation Machine | SH75 Parallel Twin Screw Extruder | 400-500 kg/h | Realize molecular bonding of materials, produce WPC granules/flakes |
| WPC Profile Extrusion Line |
Main: SJSZ65/132 Conical Twin Screw Extruder
|
150-200 kg/h | Extrude various WPC profiles via replaceable molds |
Table 3: Post-processing & Surface Treatment Technology
| Processing Type | Process Mode | Effect & Application |
|---|---|---|
| Embossing | Online 3D Embossing | Deep realistic wood grain, anti-slip function, finished product one-step forming |
| Offline Light Embossing | Soft wood grain texture, for interior decorative profiles | |
| Polishing & Brushing | Offline Sanding | Fine matte surface, enhance hand feeling |
| Offline Brushing | Deep rough wood texture | |
| Sanding + Brushing Combo | Special for co-extruded products, highly simulated log appearance |
Full WPC Production Line Workflow (From Waste to Finished Products)
Yongte provides one-stop turnkey service, integrating raw material processing, production, surface treatment and intelligent control.
| Production flow and equipment | Picture |
|
1. Plastic Recycling: Customized recycling equipment processes various waste PP/PE plastics through crushing, washing and drying to meet production standards. |
|
| 2. Wood Powder Processing: Complete wood processing unit turns raw logs into fine, dry wood powder with uniform fineness. |
|
| 3. Material Mixing: High-speed heating mixer fully blends wood powder, recycled plastic and chemical additives according to fixed formulas to ensure uniform mixing. |
|
| 4. WPC Granulation: Parallel twin-screw extruder realizes sufficient plasticization and molecular combination of mixed materials to produce high-quality WPC granules. |
|
| 5. WPC Profile Extrusion: Conical twin-screw main extruder melts and extrudes WPC materials; the tapered barrel design ensures stable pressure, and the finished product density reaches 1.3 g/cm³ with high structural strength. |
|
| 6. Co-extrusion Treatment: A layer of high-performance modified PE material is co-extruded on the product surface to improve weather resistance, anti-aging and color uniformity, suitable for long-term outdoor use. |
|
| 7. Online Surface Finishing: Equipped with 3D embossing equipment to create anti-slip wood grain, realizing one-step forming of appearance and function. |
|
| 8. Offline Polishing & Shaping: Optional sanding and brushing equipment to enrich surface textures and meet personalized aesthetic demands. |
|
Core Equipment & Service Advantages
1. Durable Hardware Configuration
- High-strength Wear-resistant Components: The screw and barrel adopt bimetallic/SKD wear-resistant materials, and the service life is 1.5-2 times longer than ordinary equipment; the machine base is made of solid steel plate, processed by CNC, supporting 20+ years of stable continuous operation.
- Anti-rust Design: All parts in contact with materials and water are made of 304 stainless steel to avoid rust and pollution.
- High-efficiency Transmission System: Heavy-duty gearbox + servo motor, high load capacity, low vibration and noise, stable operation.
2. Top-tier Electrical & Control System
Adopt internationally renowned brand components to meet EU safety standards (EN ISO 12100, EN 60204-1, EN 61000 EMC):
- Inverter: ABB | Contactor & PLC: Siemens | Temperature Controller: Omron
- Integrated full-automatic control: Auto feeding, auto temperature control, auto cutting, auto stacking, optional automatic batching system for fully unmanned production.
- Neat wiring, plug-and-play design, simple on-site installation and convenient daily maintenance.
3. Energy-saving & Efficient Production Performance
- Servo motor intelligently adjusts speed and output, reducing comprehensive energy consumption by 15-20%.
- High wood powder loading rate greatly reduces the use of recycled plastics and cuts raw material costs by 20-30%.
- Strong material compatibility: Support wood-plastic, sand-plastic, PCB-plastic, fiber-plastic and multiple composite formulas to adapt to different local waste resources of customers.
4. Global Service & Quality Assurance
- Pre-delivery Inspection: All equipment undergoes strict performance testing before delivery to ensure stable operation.
- Overseas On-site Service: Professional engineering team provides overseas on-site installation, commissioning and operator training.
- Warranty & Technical Support: 3-year warranty for core components + lifetime free technical consultation and genuine spare parts supply.
WPC Product Application
WPC products combine wood’s machinability (cuttable, sawable, strong nail holding) and plastic’s corrosion resistance (waterproof, insect-proof, mildew-proof). Relying on Yongte WPC extrusion line production line, it can produce: WPC decking, wall cladding, fence profiles, pergola components, posts and decorative panels, widely used in outdoor landscapes, architectural decoration and other fields.
Global WPC Project Cases
WPC complete plant to Canada for recycling waste fiberglass into WPC decking products
Canada Project: Turnkey production line for recycled waste fiberglass. The core layer uses recycled plastic + PCB fiberglass, matched with weather-resistant co-extrusion layer, specially producing outdoor WPC decking.
WPC Profile Machine working in Romania for making WPC decking/fence/pergola with turnkey project
Romania Project: Co-extruded WPC full line, replacing traditional single-layer products. The finished WPC decking, fences and pergolas have an outdoor service life of more than 10 years.
India Project: Aiming at road waste mixed with multi-color plastics, customized formula + anti-aging co-extruded surface layer to produce environmentally friendly building materials.
